Table cxgn.public.feature_relationshipprop

Extensible properties
for feature_relationships. Analagous structure to featureprop. This
table is largely optional and not used with a high frequency. Typical
scenarios may be if one wishes to attach additional data to a
feature_relationship - for example to say that the
feature_relationship is only true in certain contexts

Generated by
SchemaSpy

Legend:

Primary key columns

Columns with indexes

Implied relationships

Excluded column relationships

Dashed lines show
implied relationships

< n > number of related tables

Please support this project

Column

Type

Size

Nulls

Auto

Default

Children

Parents

Comments

feature_relationshipprop_id

serial

√

nextval('feature_relationshipprop_feature_relationshipprop_id_seq'::regclass)

feature_relationshipprop_pub.feature_relationshipprop_id

feature_relationshipprop_pub_feature_relationshipprop_id_fkey

feature_relationship_id

int4

feature_relationship.feature_relationship_id

feature_relationshipprop_feature_relationship_id_fkey

type_id

int4

cvterm.cvterm_id

feature_relationshipprop_type_id_fkey

The name of the
property/slot is a cvterm. The meaning of the property is defined in
that cvterm. Currently there is no standard ontology for
feature_relationship property types

value

text

2147483647

√

null

The value of the
property, represented as text. Numeric values are converted to their
text representation. This is less efficient than using native database
types, but is easier to query.

rank

int4

Property-Value
ordering. Any feature_relationship can have multiple values for any particular
property type - these are ordered in a list using rank, counting from
zero. For properties that are single-valued rather than multi-valued,
the default 0 value should be used

Table contained 0 rows at Wed May 20 01:40 EDT 2009

Indexes:

Column(s)	Type	Sort	Constraint Name
feature_relationshipprop_id	Primary key	Asc	feature_relationshipprop_pkey
feature_relationship_id + type_id + rank	Must be unique	Asc/Asc/Asc	feature_relationshipprop_c1
feature_relationship_id	Performance	Asc	feature_relationshipprop_idx1
type_id	Performance	Asc	feature_relationshipprop_idx2
